DOBERMANN
360

360 Degrees Perimeter Drone Jammer

Dobermann 360 is a powerful, 360° RF jammer engineered for area-wide drone protection. This Counter UAS jammer is designed to safeguard perimeters from drone threats by actively disrupting RF signals between drones and their operators. With advanced networked capabilities, Dobermann 360 delivers comprehensive drone mitigation, making it ideal for high-security locations or quick deployable sites in need of robust anti-drone measures.

Extreme Temperatures

Waterproof – IP67

Updated Continuously

Alarms Provided

Capability & Features

Advanced Jamming Technology

Dobermann utilizes next generation jamming technology, allowing for highly effective, reactive spot jamming. Unlike traditional broad-spectrum jammers, Dobermann targets only specific areas of the RF spectrum, minimizing interference. This approach enables safe, targeted jamming at longer distances with minimal power output, making the system both efficient and discreet. Dobermann 360 is available both with or without GNNS Jamming.

Collaborative Jamming Moded

While most jammers operate independently, the Dobermann 360 is designed for collaborative jamming. When multiple units are deployed, they work together, each radiating low power individually but achieving a high-power jamming effect in the target area. This synchronized jamming minimizes collateral disruption to surrounding areas while maximizing effectiveness against drone threats.

Flexible Operating Modes

Dobermann 360 offers manual and autonomous jamming modes to suit different operational needs:

  • Manual Mode: The operator can decide precisely when to activate jamming against a detected drone.
  • Autonomous Mode: When paired with a compatible RF drone detector, such as Watchdog 202 or Wolfpack, Dobermann 360 can automatically engage jamming when a drone is detected, providing rapid response to threats. These detectors also deliver make/model information, classifying control signals and video feeds for enhanced situational awareness.

The Situational Awareness System user interface provides complete situational awareness of the protected perimeter. Users gain real-time threat intelligence, enabling quick and informed decisions to assess and respond to potential drone incursions.

Specifications
Jamming Frequencies2.4 GHz, 5.2 GHz, 5.8 GHz & 1.6 GHz (GNNS) (Also available without GNNS Jamming)
Jamming AngleHorizontal 360° / Vertical 90°
Jamming RatioUp to 80%
Weight14,7 kg / 32,4 lbs
Length x Width x Height700 x 700 x 310 mm / 27.56x 27.56 x 12.21 in.
Operating Temperature-30°C to 65°C / -22°F to 149°F
IP ratingIP67
Communication InterfacesEthernet
Power Supply & ConsumptionPower over Ethernet+ (PoE+), < 15 W
Power Consumption200 W
ColorGrey
API for C2 IntegrationARGOS Server software to IRIS UI and other Situational Awareness Systems
